Support various types of USB2.0/1.1 and 1394 devices including CDRW,
DVDRoms, removable drives, PC video cameras, hubs, digital
camcorders/cameras and more.
It works with most 1394 equipped DV camcorder.
Features
Firewire iEEE1394
Interface
- Model No :
CVV500
- Chipset : VIA VT6306
- Two 6-pin external firewire ports,
one 6-pin internal firewire port (shared)
- PCI 2.1 compliant
- OHCI compliant 1394 host controller;
100mbit/s (12.5mb/sec); 200mbit/s (25mb/sec); 400mbit/s (50mb/sec)
- Connect up to 63 devices, internal
or external
- All 1394 ports provide upto 12V of
power
- Support Plug and play specifications
- Hot Plugging
- Complies with standard for a
iEEE1394 high performance serial bus/i-Link
- Upto 16 consecutive cable hops of
4.5 meters
- Support for digital video in full
size, full motion video of 720 by 480 pixels at 30 frames per second
- Isochronous and Asynchronous data
transfer
USB2.0
Interface
- Chipset VIA VT6212L
- One internal and
four external auto speed selectable type A USB ports for use with
USB2.0 hi-speed or USB 1.1 devices
- Connects USB2.0 hi-speed or USB 1.1
device to your PC
- Support all USB speeds. EHCI based
480 mbit/sec USB1.1 compliant
- Support driver for
Win98SE/ME/2000/XP/Server2003/XP 64 bit/Vista
|
